Step 3. Select the first calibration point. Measure the voltage across the sharing connector and enter
the data.
Front Panel Menu Reference SCPI Command
Display shows: “Enter P1 measured data”. Enter the data
from the external DVM. This should be about 1 volt. Press
Enter when done.Press Back to finish.
CAL:LEV P1
*OPC?
CAL:DATA <data>
Step 4. After the calibration completes, disconnect the voltmeter and short.
Resistance Bottom-Out Calibration
This procedure calibrates the minimum voltage that can be achieved while sinking current.
Step 1. Connect an external power supply to the + and - output terminals (see Cal Setup D).
Step 2. Set the external supply as follows: Voltage setting = (0.9 V + 0.08 * maximum output voltage of
the unit under test). The voltage must be within 10% of this value. Current limit = (0.95 * rated output
current of the unit under test). The current limit must be within 2% of this value.
Step 3. Select the resistance bottom-out calibration. Calibration takes approximately 5 seconds.
Front Panel Menu Reference SCPI Command
Select System\Admin\Cal\Misc\ResBout. Check that the
power supply is connected and select Next.
CAL:RES:BOUT
*OPC?
Step 4. After the calibration completes, disconnect the power supply.
Enter a Calibration Date
Front Panel Menu Reference SCPI Command
Select System\Admin\Cal\Date.
Enter the calibration date in the Date field. If desired, you
can enter alphanumeric data in this field.
CAL:DATE "<date>"
Save Calibration and Log Out
Front Panel Menu Reference SCPI Command
Select System\Admin\Cal\Save.
Select Save to save all calibration data.
Select System\Admin\Logout
to exit calibration mode.
To save calibration data:
CAL:SAVE
To exit calibration mode:
CAL:STAT OFF
6 Verification and Calibration
278 Keysight RP7900 Series Operating and Service Guide
