Keysight Technologies RP7945A

Minimum ESR vs. DUT Capacitance for 160 V, 10 kWunits
With local sensing and
DUT directly connected to bus bars
With remotesensing and
load leads around 6 μH/2 mΩ
160 V,10 kW unit; comp 0
160 V,10 kW unit; comp 0
160 V,10 kW unit; comp 1
160 V,10 kW unit; comp 1
160 V,10 kW unit; comp 2
160 V,10 kW unit; comp 2
1 Quick Reference
48 Keysight RP7900 Series Operating and Service Guide
