Getting Started 1

Keysight 2050/60 X-Series User’s Guide 15

Figure 1-1 U2053XA/63XA sensor

LED indicator

Indicates the U2041/42/43/44/53/63XA state.

Refer to “LED Ind icator Sequence During Power-Up for the U2053XA/

63XA Sensor” on page 40 for more information.

RF input port for

RF/microwave signals

USB cable

Physical secure lock mechanism

USB port

External trigger ports
