Keysight N9927-90001 User’s Guide 183
SA (Spectrum Analyzer) Mode
SA Mode Settings
—Then All Alignment [Auto] (to enable or disable the All Alignment) –
Default is Auto.
—or
—Then Align All Now
(to manually perform an Align All Now.) This performs
an alignment on all three individual alignments: Amptd Align Now, Burst
Align Now, and ChanEq Now). Refer to “Individual Alignments” on
page 183.
—Press Enter
If you want to disable the All Alignment [Auto], you can do so in the FieldFox
preferences (i.e., you may want to do this, for example, if you are analyzing the
amplitude stability of a signal).
Refer to the SA Individual Alignment Control setting in “Preferences” on
page 515, in Chapter 26 System Settings. See also, “Individual Alignments”.
Individual Alignments
IMPORTANT! It is recommended that you use All Alignment [Auto] or Align
All Now in lieu of the individual alignments (Amptd Align Now, Burst
Align Now, and ChanEQ Align Now), because All Alignment [Auto] and
Align All Now includes the individual alignment InstAlign Amptd Align
Now, Burst Align Now, and ChanEQ Align Now. But, if you would prefer to
have manual control over the individual alignments, then refer to the SA
Individual Alignment Control setting in “Preferences” on page 515, in
Chapter 26 System Settings.
The Individual Alignment softkey is only available, when the preference SA - Individual
Alignment Control
is set to On in the FieldFox Preferences menu. Refer to
“Preferences” on page 515, in Chapter 26 System Settings.
