Keysight CX3322A User Manual

CX3300 Device Current Waveform Analyzer  At a Glance
Model
Input
channel
Maximum
sample rate
Dynamic range (ADC bits)
Analog
band width
Memory depth
Digital
channel
CX3322A 2 1 GSa/s 14 (high speed mode) and
16 (high resolution mode)
50 MHz 4/16/64/256 Mpts
100 MHz 4/16/64/256 Mpts
200 MHz 4/16/64/256 Mpts
CX3324A 4 1 GSa/s 14 (high speed mode) and
16 (high resolution mode)
50 MHz 4/16/64/256 Mpts Yes
100 MHz 4/16/64/256 Mpts Yes
200 MHz 4/16/64/256 Mpts Yes

Keysight CX3322A Specifications

General

Brand	Keysight
Model	CX3322A
Category	Measuring Instruments
Language	English
