66 Keysight E4980A/E4980AL Precision LCR Meter
Troubleshooting
Performance test failure troubleshooting
4-
Adjustment failure troubleshooting
Table 4-12 represents the relationships between the failed adjustment and
probably faulty assembly. Note that this table lists some typical cases. There
are possibilities that another assembly may be faulty.
###: Most suspicious assembly
##: Suspicious assembly
#: Possible faulty assembly
Table 4-12 Adjustment failure troubleshooting information
Adj
Num.
First failed adjustment Probable faulty board assembly
A1 A2 A3 PPMC
1 Null DC offset adjustment ###
2 Null ADC offset adjustment ###
3 ADC Linearity adjustment ### ##
4 DC Bias adjustment ## ###
5 DC Level V Monitor adjustment ###
6 DC Level I Monitor adjustment ###
7 DC Source adjustment # ###
8 DCR adjustment ### #
9 Impedance adjustment ### #
10 AC level Monitor adjustment ### #
11 OSC Level adjustment # ###
