Keysight M8050A High-Performance BERT Getting Started Guide 23
Introduction 1
Table 10 Insertion/Extraction and Retaining
M8009A Front Panel Connectors
Table 11 M8009A Front Panel Connectors
Component Description
Retaining screws The screws on both ends of the module are used to retain the module tightly
inside the M9505A AXIe Chassis slot once you have fully placed it inside the
chassis. To remove the module, you first need to loosen these screws ensuring
that these screws disengage completely.
Module Insertion/Extraction
Handles
The handles on both sides of the module to insert or eject the module from the
slot of the M9505A AXIe Chassis.
The inputs of the M8009A module are sensitive to static electricity.
Therefore, take necessary anti-static precautions, such as wearing a
grounded wrist strap, to minimize the possibility of electrostatic damage.
Connector Description
Clk Out 16G 15.625 MHz to 16 GHz clean or jittered
Sync In Reserved for future use
Sync Out A/B/C For sync with M8042A
Ch Clk Out 1/2 To provide clock M8042A
Sys Trig In A/B Reserved for future use
Ref Clk In Reference clock for synthesizer
Ref Clk Out 10/100 MHz
Ref Clk Out 16G For DCA, PTB, clean
