8 N5186A MXG and X-Series SA Measurement Guide
Basic Measurements
Overview
Overview
Keysight’s N5186A MXG is optimized to be your ideal signal generator with the
outstanding performance you desire, all in one easy-to-use box capable of
signal generation up to 8.5 GHz with 960 MHz of modulation bandwidth per
channel.
The measurement examples use an X-Series Signal Analyzer to view the
results. For information on using the Signal Analyzer multi-touch user
interface, refer to the Online Help.
Please refer to the MXG data sheet and signal analyzer data sheet to ensure your
measurement setup has adequate power.
https://www.keysight.com/us/en/product/N5186A/N5186A.html
The software versions used in this measurement guide are:
— MXG: A.13.01
— Signal Analyzer/N9063EM0E: Version 2021 A.31.xx or later
— 89601 VSA: Version 2019
