Keysight NFA Series Noise Figure Analyzers Service Guide 369
Replaceable Parts
Hardware
Figure 14-6 Disk Drive Tray Assembly
Table 14-8
Item Description Keysight Part Number
1 A5 Disk Drive Replacement Kit N9020-60202
2 A5MP1 Disk Drive Tray W1312-40078
3 A5MP2 Disk Drive Rear Panel W1312-00103
4 A5MP3 Disk Drive Assembly Handle 1440-0421
5 Screw M3 x 0.5 (8 mm long)
(For rev 6 and earlier of drive tray.
For rev 7 and later, use 0515-1035 M3 (8 mm Flat-HD))
0515-0372
6 Screw M2.5 x 0.45 (5 mm long) 0515-2219
7 Screw M3 x 0.5 (6 mm long) 0515-1946
