Keysight N8976B

Keysight NFA Series Noise Figure Analyzers Service Guide 435
Assembly Replacement Procedures
A5 Solid State Drive
A5 Solid State Drive
Disk Drive
Removal
1. Refer to Figure 15-35. Loosen the thumb screw (2) and pull the SSD (1)
out of the CPU assembly.
Figure 15-35 SSD Removal
To remove the SSD or the memory card, it is not necessary to remove the
CPU assembly from the chassis.
