386 Keysight NFA Series Noise Figure Analyzers Service Guide
Replaceable Parts
Hardware
Figure 14-21 Front Frame Parts
Table 14-22
Item Description Keysight Part Number
1 A1MP14 Shield N9020-00066
2 A1A1 Front Frame N9020-60299
3 A1MP10 Bracket front panel shield N9020-00064
4 A1A2 Front Panel Control Board N9020-63274
5 A1MP11 Display Bracket, Front Panel N9020-00078
A1W1 Flex Circuit, Display to Front Panel Control Board N9020-60273
A1W2 Cable Assembly, Backlight N9020-60217
