Keysight N9010B EXA Signal Analyzer Service Guide 121
Instrument Messages
Condition Messages
207 2 Burst not
found;with
selected Time
Slot
E The selected timeslot does not contain the expected
burst.
209 3 Timing Error E
209 3 Timing Error:No
time ref pilot
burst
E The pilot burst used for time reference is not active.
211 4 Carrier(s)
incorrect or
missing
E In PSA, this error was reported as one of the following
error numbers: 10165, 10173, 10178, 10419, 10421,
10535, 10560, 10642, 10648, 10650, 10960
213 5 Freq Out of Range E
213 5 Freq Out of
Range; System
input (IF)
E One or more system input frequencies are out of range.
If using a frequency list, check that all entries are valid
for current measurement mode.
213 5 Freq Out of
Range; External
LO
E One or more external LO frequencies are out of range.
Check that the LO frequency limits are set correctly and
check the entered measurement frequencies and
measurement mode.
215 6 Sync Error E W-CDMA: Cannot sync DPCCH pilot.
Cannot synchronize measurement with DPCCH pilot for
Power Control measurement, because the pilot signal
cannot be found. Make sure DPCCH is present in the
W-CDMA uplink signal, and that the slot format and
scramble code are set correctly.
215 6 Sync Error;No
pilot burst
E There is no Pilot burst detected.
215 6 Sync Error;Sync
code not found
E Synchronization code is not found in the measured time
slot.
215 6 Sync Error;No
freq ref pilot
burst
E The pilot burst used for frequency reference is not
active.
215 6 Sync
Error;Midamble
sync fail
E Failed to find the uplink slot, which caused the
synchronization with the Midamble to fail.
215 6 Sync
Error;Preamble
length zero
E Burst type is "Data" or "Preamble" and the
measurement cannot find a Preamble
Err# Bit in
status
register
Message Error or
Warning
More Information
