234 Keysight N9010B EXA Signal Analyzer Service Guide
Front End Control Troubleshooting
A15 Front End Control Description
Table 6-1 A15 Option Related Control
Option Description Physical Location in Analyzer A15 Support
P03 Preamplifier, 3.6 GHz A15 to A13 EFEC-Lite or EFEC
P07 Preamplifier, 7.0 GHz A15 to A11 EFEC-Lite or EFEC
P13 Preamplifier, 13.6 GHz A15 to A11 EFEC-Lite or EFEC
P26 Preamplifier, 26.5 GHz A15 to A11 EFEC-Lite or EFEC
P32 Preamplifier, 32 GHz A15 to A11 EFEC
P44 Preamplifier, 44 GHz A15 to A11 EFEC
CRP Arbitrary IF Output A15 to AUX IF OUT (rear panel) EFEC
CR3 Second IF Output A15 to AUX IF OUT (rear panel) EFEC
MPB Microwave Preselector Bypass A15 to SW1 and SW2 EFEC
EA3 Electronic Attenuator, 3.6 GHz A15 to A13 EFEC-Lite or EFEC
B40 40 MHz Analysis Bandwidth A15 to A3 EFEC
DP2 Digital Signal Processing &
2 GB Capture Memory
A15 to A3 EFEC
532 Frequency Range, 32 GHz A15 to A13 EFEC
544 Frequency Range, 44 GHz A15 to A13 EFEC
