396 Keysight N9010B EXA Signal Analyzer Service Guide
Replaceable Parts
Replaceable Parts
SW4 Transfer Switch, 50 GHz
(Options B40, MPB, or DP2)
87222-60031
W1 Cable, Front Panel Interface Board to Motherboard (Ribbon) N9020-60216
W2 Cable, Interconnect from A2J820 to A3J20 N9020-60046
W3 Cable Assembly, A11J2 to A13J2 (semi-rigid)
Option 503, 507, 513, 526 N9020-20101
Option 532, 544 N9020-20131
W4 Cable Assembly, A14J740 to A13J4 (semi-rigid) N9020-20156
W5 Cable Assembly, A16J702 to A13J1 (semi-rigid) N9020-20064
W6 Cable Assembly, A16J703 to A14J200 (semi-rigid) N9020-20033
W7 Cable Assembly, A12 Output to A13J9 (semi-rigid)
Option 503, 507, 513, 526 N9020-20124
Option 532, 544 N9010-20006
W8 Cable Assembly, A11J3 to A12 Input (semi-rigid)
Option 503, 507, 513, 526 N9020-20123
Option 532, 544 N9010-20005
W9 Cable Assembly, A10 Output to A11J1 (semi-rigid)
Option 503, 507, 513, 526 N9020-20153
Option 532, 544 N9010-20004
W10 Cable Assembly, J1 to A9 Input (semi-rigid)
Option 503, 507, 513, 526 N9020-20141
Option 532, 544 N9020-20133
W11 Cable Assembly, A9 Output to A10 Input (semi-rigid)
Option 503, 507, 513, 526 N9020-20142
Option 532, 544 N9010-20002
W12 Cable Assembly, A16J710 to A3J14 (Flexible Coax) 8121-1401
W13 Cable Assembly, A2J601 to A3J15 (Flexible Coax) 8121-1411
W14 Cable Assembly, A16J711 to A2J300 (Flexible Coax) 8121-1401
W15 Cable Assembly, A13J7 to A2J100 (Flexible Coax) 8121-1400
Table 14-1 All Replaceable Parts
Reference
Designator
Description Part Number
