3 Short-Range Comms & IoT Mode
3.4 HRP UWB Demodulation Measurement
SFD #
Sets which SFD (start-of-frame delimiter) sequence is used for UWB
synchronization header (SHR).
Remote Command
[:SENSe]:HUWB:SHR:SFD:NUMBer <integer>
[:SENSe]:HUWB:SHR:SFD:NUMBer?
Example
:HUWB:SHR:SFD:NUMB 2
:HUWB:SHR:SFD:NUMB?
Dependencies Only available when "PHY Mode" on page 501 is ERDEV-HPRF or ERDEV-BPRF
Valid values:
ERDEV-BPRF: 0, 2
ERDEV-HPRF: 1-4
Preset 2
State Saved Saved in instrument state
Min 0
Max 4
SFD Length
Sets the number of Si symbols—each symbol multiplied by one of the values (0, 1, -
1)—used to comprise the SFD portion of the UWB synchronization header (SHR).
Remote Command
[:SENSe]:HUWB:SHR:SFD:LENGth L8 | L64
[:SENSe]:HUWB:SHR:SFD:LENGth?
Example
:HUWB:SHR:SFD:LENG L64
Couplings Only available when "PHY Mode" on page 501 is Non-ERDEV
Preset
L64
State Saved Saved in instrument state
Range
8|64
RSF Parameters
MMRS Sequence
Select the type of MMRS sequence:
