3 VMA Mode
3.9 SEM Measurement
Mode Values
LTEAFDD,
LTEATDD
-5.5 dBm, -12.5 dBm, -15.0 dBm, -15.0 dBm, -15.0 dBm, -15.0 dBm, -15.0
dBm, -15.0 dBm, -15.0 dBm, -15.0 dBm, -15.0 dBm, -15.0 dBm|-13.5 dBm, -
8.5 dBm, -11.5 dBm, -23.5 dBm, -23.5 dBm, -23.5 dBm, -23.5 dBm, -23.5
dBm, -23.5 dBm, -23.5 dBm, -23.5 dBm, -23.5 dBm
5G NR -5.5 dBm, -12.5 dBm, -15.0 dBm, -15.0 dBm, -15.0 dBm, -15.0 dBm, -15.0
dBm, -15.0 dBm, -15.0 dBm, -15.0 dBm, -15.0 dBm, -15.0 dBm|-22.5 dBm, -
8.5 dBm, -11.5 dBm, -23.5 dBm, -23.5 dBm, -23.5 dBm, -23.5 dBm, -23.5
dBm, -23.5 dBm, -23.5 dBm, -23.5 dBm, -23.5 dBm
MSR -12.5 dBm, -12.5 dBm, -24.5 dBm, -11.5 dBm, -15.0 dBm, -15.0 dBm, -15.0
dBm, -15.0 dBm, -15.0 dBm, -15.0 dBm, -15.0 dBm, -15.0 dBm| -12.5 dBm, -
12.5 dBm, -24.5 dBm, -11.5 dBm, -15.0 dBm, -15.0 dBm, -15.0 dBm, -15.0
dBm, -15.0 dBm, -15.0 dBm, -15.0 dBm, -15.0 dBm
When the max number of offsets is 14 in these Modes, the preset value of Offset G ~ N is the same as
the Offset F value
WLAN Mode: See the table of "WLAN Mode Presets" on page 1508 below
State Saved Saved in instrument state
Min/Max -200 dBm/50 dBm
WLAN Mode Presets
Radio Std Presets
802.11b/g(DSSS/CCK/PBCC) -10 dBm, -30 dBm, -30 dBm, -30 dBm, -30 dBm, -30 dBm, -30
dBm, -30 dBm, -30 dBm, -30 dBm, -30 dBm, -30 dBm, -30 dBm,
-30 dBm
802.11a/g(OFDM/DSSS-
OFDM)
802.11n/ac/ax/be (20MHz)
-63.00 dBm, -63.00 dBm, -63.00 dBm, -63.00 dBm, -63.00 dBm,
-63.00 dBm, -63.00 dBm, -63.00 dBm, -63.00 dBm, -63.00 dBm,
-63.00 dBm, -63.00 dBm, -63.00 dBm, -63.00 dBm
802.11n/ac/ax/be (40MHz) -66.00 dBm, -66.00 dBm, -66.00 dBm, -66.00 dBm, -66.00 dBm,
-66.00 dBm, -66.00 dBm, -66.00 dBm, -66.00 dBm,-66.00 dBm,
-66.00 dBm,-66.00 dBm, -66.00 dBm
802.11ac/ax(80MHz/160MHz) -69.00 dBm, -69.00 dBm, -69.00 dBm, -69.00 dBm, -69.00 dBm,
-69.00 dBm, -69.00 dBm, -69.00 dBm, -69.00 dBm, -69.00 dBm,
-69.00 dBm, -69.00 dBm, -69.00 dBm, -69.00 dBm
802.11be
(80MHz/160MHz/320MHz)
-49.00 dBm, -49.00 dBm, -49.00 dBm, -49.00 dBm, -49.00 dBm,
-49.00 dBm, -49.00 dBm, -49.00 dBm, -49.00 dBm, -49.00 dBm,
-49.00 dBm, -49.00 dBm, -49.00 dBm, -49.00 dBm
802.11ac/ax (80 MHz + 80
MHz)
-69.00 dBm, -69.00 dBm, -69.00 dBm, -69.00 dBm, -69.00 dBm,
-69.00 dBm, -69.00 dBm, -69.00 dBm, -69.00 dBm, -69.00 dBm,
-69.00 dBm, -69.00 dBm, -69.00 dBm, -69.00 dBm
802.11ah (1MHz) 16.00 dBm, -4.00 dBm, -12.00 dBm, -60.00 dBm, -60.00 dBm, -
60.00 dBm, -60.00 dBm, -60.00 dBm, -60.00 dBm, -60.00 dBm, -
Vector Modulation Analyzer Mode User's &Programmer's Reference 1508
