242 Keysight N9927-90001 User’s Guide
IQ Analyzer (IQA) – Option 351 (CPU2 Only)
I/Q Analyzer (IQA) Mode Settings
— Stop immediately stops the I/Q data file capture and stops writing
data to the current I/Q data file (no data is saved). If the I/Q data was
being saved when the Stop softkey is pressed, the file is deleted.
Refer to “Example:” on page 243.
Each time you press the Start softkey the I/Q data writes to the current
filename (i.e., Single capture default is IQDataFile.csv or for Multiple
format is IQDataFile_yyyymmdd hh.mm.ss.ffff.csv). To avoid overwriting
your Single capture data or to add a unique filename for Single or Multiple
capture data, use the Measure 1 > Capture Data Settings > File Settings >
Filename softkey to modify your filename Refer to the File Count softkey
on page 240.

Keysight N9913A Specifications

General

Amplitude Accuracy	±0.5 dB
Tracking Generator	Yes
Operating Temperature	-10°C to +50°C
Storage Temperature	-40°C to +70°C
Dynamic Range	> 100 dB
Measurement Types	Cable and antenna analyzer, spectrum analyzer
Battery Life	4 hours (typical)
Impedance	50 Ohm
Distance-to-Fault (DTF)	Up to 1000 m
Interface	USB, LAN
