488 Keysight N9927-90001 User’s Guide
System Settings
System Configuration
—Then Options (Licensing)
—Then Install Options The FieldFox reads, validates, then installs the options.
— Press and hold the power button to shut down, then restart the FieldFox.
How to Delete ALL Options
Deleting individual options is NOT supported.
—Press System 7
—Then System Configuration
—Then Options (Licensing)
—Then Advanced
—Then Delete All Options
After a warning message, all options on the FieldFox are deleted.
For more information about Licensing, see the FieldFox Service Manual at:
http://na.support.keysight.com/fieldfox.
GPS
GPS (Global Positioning System) allows you to ‘stamp’ each data trace with
your physical position in latitude/longitude/elevation format. This can be
useful when making measurements on cell towers or other antennas at remote
locations.
— With Option 307, GPS is available with the built-in receiver accessed
through the top-panel SMA (f) connector. This connector has a 3.3 VDC
bias voltage which is switched ON when GPS is set to Internal. This system
is designed for use with an active antenna such as the Keysight
N9910X-825.
— Without Option 307, GPS is usable ONLY with an external GPS receiver that
is shipped with Microsoft “Streets and Trips” and “AutoRoute”. The GPS
receiver is NOT available from Keysight. Only the GPS USB receiver is used
with the FieldFox. Therefore, it is NOT necessary to purchase the very latest
version of the map software.
How to make GPS settings
GPS settings are the same with, or without, Option 307.
— Your GPS settings can be saved with Preferences. Learn more in “Quick
Settings Table” on page 477.
—Press System 7
Delete All CFG Options is to be used by Service Personnel ONLY.
