Keysight PNA-X Series Configuration Guide

Page 33
Find us at www.keysight.com
Description Required Option For PNA-X
Series
For PNA
Series
For PNA-L
Series
User
Installable
Test set and power configuration
Add configurable test set, 4-ports N522xB-400 N/A N522xBU-401 N/A No
Add configurable test set and source
attenuators, 4-ports
N523xB-400 N/A N/A N523xBU-416 No
Add extended power range, 4-ports
1
N522x/4xB-401 N524xBU-417 N522xBU-417 N/A No
Add bias-tees, 4-ports
1
N522x/4xB-417 or
N524xB-422
N524xBU-419 N522xBU-419 N/A No
Add extended power range and bias tees,
4-ports
N5227/47B-401 N5247BU-419 N5227BU-419 N/A No
Add internal combiner and mechanical
switches, 4-ports
N524xB-417/419 N524xBU-423 N/A N/A No
Add low frequency extension, 4-ports N522xB-401, 417, 419, or
N524xB-422, 423
N524xBU-425 N522xBU-405 (for 401),
N522xBU-420 (for 417
or 419)
N/A No
Add low-noise receiver, 2-ports N524xB-21x, 22x N524xBU-229 N/A N/A No
Add low-noise receiver, 4-ports N524xB-41x, 42x N524xBU-429 N/A N/A No
Pulse, antenna, mm-wave
Add pulse modulator to internal 1st source N524xBU-021 N522xBU-021 N/A Yes
Add pulse modulator to internal 2nd source Requires one of Options
22x, 40x, 41x, or 42x
N524xBU-022 N522xBU-022 N/A Yes
Add IF inputs N524xBU-020 N522xBU-020 N/A Yes
A to B model upgrades
The A to B model upgrade kit includes a new front-panel assembly
with 12.1” multi-touch display, a new solid-state hard drive, and a new
instrument cover and handles with Keysight’s dark-gray color scheme
2
N524xAU-690 N522xAU-690 N523xAU-690 No
PNA Family Network Analyzer Upgrade Kits (Continued)
1. Not available on N5227/47B.
2. May also require update of CPU, SPAM, and synthesizer assemblies, supplied in separate upgrade kits.
For more information, visit na.support.keysight.com/pna

Keysight PNA-X Series Specifications

General

Output Power	+13 dBm (typical)
Number of Ports	2 or 4
Dimensions	426 mm (W) x 470 mm (D)
Power Requirements	100 to 240 VAC, 50/60 Hz
Frequency Range	10 MHz to 26.5 GHz (varies by model)
