Keysight PNA-X Series Configuration Guide

Page 7
Find us at www.keysight.com
Application software
1
The S93xxxB software products replace the S93xxxAs, and the S93xxxAs will be discontinued in June 2019.
Description For PNA-X
Series
For PNA
Series
For PNA-L
Series
Additional Information
Automatic fixture removal S93007B/A S93007B/A S93007B/A
Time domain analysis S93010B/A S93010B/A S93010B/A
Enhanced time domain analysis with
TDR
S93011B/A S93011B/A S93011B/A Includes all capability of S93010B/A
Does not work with Low-frequency extension (LFE)
Real time S-parameter and power
measurement uncertainty
S93015B/A S93015B/A S93015B/A
5
Displays the measurement uncertainty dynamically (real-time)
on the measurement trace
Basic pulsed-RF measurements S93025B/A S93025B/A N/A Includes control of internal pulse generators and provides
pulse widths to 200 ns using wideband detection
Advanced pulsed-RF measurements S93026B/A S93026B/A N/A Includes all capability of S93025B/A, and provides pulse
widths to 100 ns using wideband detection, and 20 ns using
narrowband detection
Add mechanical noise tuner control for
noise figure/parameter measurements
S93027B/A N/A N/A Provides ability to control Maury Microwave’s LXI impedance
tuners. Requires application software S93029B/A.
Noise figure measurements with vector
correction
2
S93029B/A S93029B/A N/A Standard receivers are used if hardware option N524xB-029
is not present
Frequency-offset measurements
S93080B/A S93080B/A S93080B/A Provides ability to independently set the frequency
of internal sources and receivers, and to configure
external sources. This functionality is included with
S93029/082/083/084/086/087/089/090x/093/094B/A or
S94510/511A.
Scalar mixer/converter measurements S93082B/A S93082B/A S93082B/A Provides SMC measurement class. S93082B/A is a subset of
S93083B/A
Vector and scalar mixer/converter
measurements
3
S93083B/A S93083B/A N/A Provides SMC+Phase and VMC measurement classes
Embedded-LO capability S93084B/A S93084B/A N/A Works with S93029/082/083/086/087B/A
Gain-compression measurements S93086B/A S93086B/A N/A
Intermodulation distortion measurements
4
S93087B/A S93087B/A N/A Not available with PNA test set options 200, 210, 400, and 410
Source phase control S93088B/A S93088B/A N/A
Differential and I/Q device measurements S93089B/A S93089B/A N/A Requires a 4-port test set option (4xx)
1. The S9xxxxA software license types are fixed-perpetual (1FP), transportable-perpetual (1TP), fixed-1-year (1FY), and transportable-1-year (1TY). The
S93xxxB software has four license types: Node-locked, Transportable, USB Portable and Floating/Network, and has four term choices for each perpetual
and time-based types. Please refer to “Keysight Software Licensing Options, Provide Flexibility and Support” on page 29 for more details. The fixed-per-
petual (1FP) is the only license type that can be ordered as part of the instrument and installed. The other license types must be ordered separately and
installed from the web after the receipt of the instrument.
2. For N522xB and N5241/42/49B, vector-noise-corrected measurements require an ECal for use as an impedance tuner. For N5244/45/47B with Option 029,
an internal tuner is included. Noise calibration requires a power meter when using a standard receiver. When using the low-noise receiver (Option 029),
either a power meter or a 346-series noise source is required (Keysight 346C or 346C-K01 recommended). A power meter is required for measuring mixers
and converters.
3. A configurable test set is required for VMC measurements to connect a reference mixer, or for SMC+Phase measurements using the comb-generator-based
calibration. When ordered with PNA test set Options 200, 210, 400, or 410 (no front-panel jumpers), phase and delay measurements can only by done using
SMC+Phase with a calibration mixer.
4. S93087B/A can be used without PNA-X Options 22x or 42x, but exernal equipment such as a signal generator and a combiner may be required.
Refer to page 20 for more details.
5. S93015B/A is not available on N5231B, N5232B and N5239B.
PNA Family Network Analyzer Configurations (Continued)
PNA-X Series PNA Series PNA-L Series Test Port Connector
N5249B 900 Hz/10 MHz to 8.5 GHz N5239B 300 kHz to 8.5 GHz 3.5 mm (male)
N5241B 900 Hz/10 MHz to 13.5 GHz N5221B 900 Hz/10 MHz to 13.5 GHz N5231B 300 kHz to 13.5 GHz 3.5 mm (male)
N5242B 900 Hz/10 MHz to 26.5 GHz N5222B 900 Hz/10 MHz to 26.5 GHz N5232B 300 kHz to 20 GHz 3.5 mm (male)
N5244B 900 Hz/10 MHz to 43.5 GHz N5224B 900 Hz/10 MHz to 43.5 GHz N5234B 10 MHz to 43.5 GHz 2.4 mm (male)
N5245B 900 Hz/10 MHz to 50 GHz N5225B 900 Hz/10 MHz to 50 GHz N5235B 10 MHz to 50 GHz 2.4 mm (male)
N5247B 900 Hz/10 MHz to 67 GHz N5227B 900 Hz/10 MHz to 67 GHz 1.85 mm (male)

Keysight PNA-X Series Specifications

General

Output Power	+13 dBm (typical)
Number of Ports	2 or 4
Dimensions	426 mm (W) x 470 mm (D)
Power Requirements	100 to 240 VAC, 50/60 Hz
Frequency Range	10 MHz to 26.5 GHz (varies by model)
