Keysight PNA-X Series Configuration Guide

Page 9
Find us at www.keysight.com
Accessories, calibration options
Description For PNA-X Series For PNA Series For PNA-L Series Additional information
Accessories
Rack mount kit for use without handles N524xB-1CM N522xB-1CM N523xB-1CM
Rack mount kit for use with handles N524xB-1CP N522xB-1CP N523xB-1CP
Pulse I/O adapter N1966A N1966A N/A
Comb generator
1
U9391C/F/G N/A N/A
Calibration software
Built-in performance test software for standard compliant
calibration
2
S93898B/A S93898B/A S93898B/A
Calibration documentation
ISO 17025 compliant calibration N524xB-1A7 N522xB-1A7 N523xB-1A7
Commercial calibration certificate with test data N524xB-UK6 N522xB-UK6 N523xB-UK6
ANSI Z540 compliant calibration N524xB-A6J N522xB-A6J N523xB-A6J
PNA Family Network Analyzer Configurations (Continued)
1. A fully configured NVNA system requires two comb generators with power supplies, Keysight calibration kits
(mechanical or ECal), and a power meter and sensor or USB power sensor.
2. Additional hardware required. Please refer to the analyzer’s service guide for required service-test
equipment.
PNA-X Series PNA Series PNA-L Series Test Port Connector
N5249B 900 Hz/10 MHz to 8.5 GHz N5239B 300 kHz to 8.5 GHz 3.5 mm (male)
N5241B 900 Hz/10 MHz to 13.5 GHz N5221B 900 Hz/10 MHz to 13.5 GHz N5231B 300 kHz to 13.5 GHz 3.5 mm (male)
N5242B 900 Hz/10 MHz to 26.5 GHz N5222B 900 Hz/10 MHz to 26.5 GHz N5232B 300 kHz to 20 GHz 3.5 mm (male)
N5244B 900 Hz/10 MHz to 43.5 GHz N5224B 900 Hz/10 MHz to 43.5 GHz N5234B 10 MHz to 43.5 GHz 2.4 mm (male)
N5245B 900 Hz/10 MHz to 50 GHz N5225B 900 Hz/10 MHz to 50 GHz N5235B 10 MHz to 50 GHz 2.4 mm (male)
N5247B 900 Hz/10 MHz to 67 GHz N5227B 900 Hz/10 MHz to 67 GHz 1.85 mm (male)

Keysight PNA-X Series Specifications

General

Output Power	+13 dBm (typical)
Number of Ports	2 or 4
Dimensions	426 mm (W) x 470 mm (D)
Power Requirements	100 to 240 VAC, 50/60 Hz
Frequency Range	10 MHz to 26.5 GHz (varies by model)
