Keysight PNA-X Series Configuration Guide

Page 5
Find us at www.keysight.com
PNA Family Network Analyzer Configurations
Test set and power configuration options
Choose one test set and power configuration option. Option 2xx indicates two test ports. Option 4xx indicates four test ports. To add
options to a product, order the corresponding item number (N52xxB-xxx).
Description Configurable
test set
Source
attenuators
Receiver
attenuators
Bias-tees Internal
second
source
Internal
combiner
Mechanical
switches
Low-
frequency
extension
(down to
900 Hz)
Additional information
PNA-X Series
Option 201 ⦁
Option 205 ⦁ ⦁ only available on N5241B/42B
Option 217
⦁ ⦁ ⦁
Option 219
⦁
⦁ ⦁
⦁
Option 222
1
⦁ ⦁
⦁
⦁
⦁ ⦁
Not available on 67 GHz model
Option 224
1
⦁ ⦁ ⦁ ⦁ ⦁ ⦁ ⦁
Option 401
1
⦁ ⦁
Option 417
1
⦁ ⦁ ⦁ ⦁ Not available on 67 GHz model
Option 419
1
⦁ ⦁ ⦁ ⦁ ⦁
Option 422
1
⦁ ⦁ ⦁ ⦁ ⦁ ⦁ Not available on 67 GHz model
Option 423
1
⦁ ⦁ ⦁ ⦁ ⦁ ⦁ ⦁
Option 425
1
⦁ ⦁ ⦁ ⦁ ⦁ ⦁ ⦁ ⦁
PNA Series
Option 200
Option 201 ⦁
Option 205 ⦁ ⦁ ⦁ Only available on N5221/22/27B
Option 210 2-port metrology option
Option 217 ⦁ ⦁ ⦁ Not available on 67 GHz model
Option 219 ⦁ ⦁ ⦁ ⦁
Option 220 ⦁ ⦁ ⦁ ⦁ ⦁
Option 400
1
⦁
Option 401
1
⦁ ⦁
Option 405 ⦁ ⦁ ⦁
Option 410
1
⦁ 4-port metrology option
Option 417
1
⦁ ⦁ ⦁ ⦁ Not available on 67 GHz model
Option 419
1
⦁ ⦁ ⦁ ⦁ ⦁
Option 420 ⦁ ⦁ ⦁ ⦁ ⦁ ⦁
PNA-L Series
Option 200
Option 216 ⦁ ⦁
Option 400 Available on only N5231/32B
Option 416
2
⦁ ⦁ Available on only N5231/32B
PNA-X Series PNA Series PNA-L Series Test Port Connector
N5249B 900 Hz/10 MHz to 8.5 GHz N5239B 300 kHz to 8.5 GHz 3.5 mm (male)
N5241B 900 Hz/10 MHz to 13.5 GHz N5221B 900 Hz/10 MHz to 13.5 GHz N5231B 300 kHz to 13.5 GHz 3.5 mm (male)
N5242B 900 Hz/10 MHz to 26.5 GHz N5222B 900 Hz/10 MHz to 26.5 GHz N5232B 300 kHz to 20 GHz 3.5 mm (male)
N5244B 900 Hz/10 MHz to 43.5 GHz N5224B 900 Hz/10 MHz to 43.5 GHz N5234B 10 MHz to 43.5 GHz 2.4 mm (male)
N5245B 900 Hz/10 MHz to 50 GHz N5225B 900 Hz/10 MHz to 50 GHz N5235B 10 MHz to 50 GHz 2.4 mm (male)
N5247B 900 Hz/10 MHz to 67 GHz N5227B 900 Hz/10 MHz to 67 GHz 1.85 mm (male)
1. To independently control the frequency of the second internal source, one of the following software
applications is required: S93080/029/082/083/084/086/087/089/090x/093/094A, or S94510/511A.
2. Adds one source attenuator to be shared with all test ports.

Keysight PNA-X Series Specifications

General

Output Power	+13 dBm (typical)
Number of Ports	2 or 4
Dimensions	426 mm (W) x 470 mm (D)
Power Requirements	100 to 240 VAC, 50/60 Hz
Frequency Range	10 MHz to 26.5 GHz (varies by model)
