Keysight PNA-X Series Configuration Guide

Page 44
Find us at www.keysight.com
1. Special rugged female connector specifically for connecting to the
network analyzer test port, but does not mate with a standard male
connector.
2. The PNA Series must have firmware revision A.12.85.00 or above for the
operation with the N469xD Series ECal.
For devices with Type-N connectors
Mechanical calibration kits
85054B standard: DC to 18 GHz. Includes:
– 00909-60011 Type-N (m) fixed lowband load
– 00909-60012 Type-N (f) fixed lowband load
– 85054-60025 Type-N (m) short
– 85054-60026 Type-N (f) short
– 85054-60027 Type-N (m) open
– 85054-60028 Type-N (f) open
– 85054-60031 Type-N (f) to 7mm adapter
– 85054-60032 Type-N (m) to 7mm adapter
– 85054-60037 Type-N (f) to Type-N (f) adapter
– 85054-60038 Type-N (m) to Type-N (m) adapter
– 85054-80010 Type-N (f) sliding load
– 85054-80009 Type-N (m) sliding load
– 85054-60050 Type-N (f) connector gage
– 85054-60052 Type-N (f) gage master
– 85054-60051 Type-N (m) connector gage
– 85054-60053 Type-N (m) gage master
85054D economy: DC to 18 GHz. Includes:
– 85054-60025 Type-N (m) short
– 85054-60026 Type-N (f) short
– 85054-60027 Type-N (m) open
– 85054-60028 Type-N (f) open
– 85054-60031 Type-N (f) to 7mm adapter
– 85054-60032 Type-N (m) to 7mm adapter
– 85054-60037 Type-N (f) to Type-N (f) adapter
– 85054-60038 Type-N (m) to Type-N (m) adapter
– 85054-60046 Type-N (m) fixed load
– 85054-60047 Type-N (f) fixed load
Adapter sets
– 85130C 3.5 mm to Type-N
Electronic calibration kits
N4431B Microwave ECal: 300 kHz to 13.5 GHz, 4-ports. Includes:
– Option 020 module with: N4431-60007 4 x Type-N (f) ECal
module
N4432A Microwave ECal: 300 kHz to 18 GHz, 4-ports. Includes:
– Option 020 module with: N4432-60003 4 x Type-N (f) ECal
module
N4432A-xxx mixed-connector options:
Connector type Port A
option
Port B
option
Port C
option
Port D
option
3.5 mm (f) 101 201 301 401
3.5 mm (m) 102 202 302 402
Type-N 50 ohm (f) 103 203 303 403
Type-N 50 ohm (m) 104 204 304 404
Option 150: Replaces standard storage container with a wooden
box
N4690B Microwave ECal: 300 kHz to 18 GHz, 2-ports. Includes:
– Option M0F module with: N4690-60004 Type-N (f) to
Type-N (m) ECal module
– Option 00M module with: N4690-60005 Type-N (m) to
Type-N (m) ECal module
– Option 00F module with: N4690-60006 Type-N (f) to Type-N
(f) ECal module
– Option 00A adds:
– 85054-60037 Type-N (f) to Type-N (f) adapter
– 85054-60038 Type-N (m) to Type-N (m) adapter
N4690D
2
Microwave ECal: DC or 300 kHz to 18 GHz, 2-ports.
Includes:
– Option F0F: Both connectors are Type-N 50 Ω female on
module
– Option M0F: 1 female and 1 male Type-N 50 Ω connector on
module
– Option M0M: Both connectors are Type-N 50 Ω male on
module
– Option 0DC: DC to 18 GHz
– Option 003: 300 kHz to 18 GHz
– Option 00A adds:
– 85054-60037 Type-N (f) to Type-N (f) adapter
– 85054-60038 Type-N (m) to Type-N (m) adapter
Cables
Use the test port cables recommended for devices with 7 mm
connectors, and 7 mm to Type-N adapters that are from the
85054B/D Type-N calibration kit (see 7 mm connector section).
Option 150: Replaces standard storage container with a wooden
box
N4431B-xxx mixed-connector options:
Connector type Port A
option
Port B
option
Port C
option
Port D
option
3.5 mm (f) 101 201 301 401
3.5 mm (m) 102 202 302 402
Type-N 50 ohm (f) 103 203 303 403
Type-N 50 ohm (m) 104 204 304 404
7-16 (f)
1
105 205 305 405
7-16 (m)
1
106 206 306 406
Option 150: Replaces standard storage container with a wooden
box
