Keysight PNA-X Series Configuration Guide

Page 32
Find us at www.keysight.com
1. Frequency upgrade options from 8.5/13.5/20/26.5 GHz to 43.5/50 GHz and 43.5/50 GHz to 67 GHz are not
available. Trade-in is recommended.
2. Not available on N5227/47B.
Description Required Option For PNA-X
Series
For PNA
Series
For PNA-L
Series
User
Installable
Frequency upgrade
1
Extend analyzer's frequency range to 13.5 GHz N5239/49B N5249BU-613 N/A N5239BU-613 No
Extend analyzer's frequency range to 20 GHz N5231/39B N/A N/A N5231/39BU-620 No
Extend analyzer's frequency range to 26.5 GHz N5221/41/49B N5241/49BU-626 N5221BU-626 N/A No
Extend analyzer's frequency range to 50 GHz N5224/34/44B N5244BU-650 N5224BU-650 N5234BU-650 No
Test ports
Expand 2-ports, single source without configurable
test set to 4-ports
N522xB-200 N/A N522xBU-600 N/A No
Expand 2-ports, single source with configurable test
set to 4-ports
N522x/4xB-201 N524xBU-601 N522xBU-601 N/A No
Expand 2-ports, single source with configurable test
set and low-frequency extension to 4-ports
N522xB-205 N/A N522xBU-605 N/A No
Expand 2-ports, single source with configurable test
set and extended power range to 4-ports
N522x/4xB-217 N524xBU-617 N522xBU-617 N/A No
Expand 2-ports, single source with configurable test
set, extended power range, and bias-tees to 4-ports
N522x/4xB-219 N524xBU-619 N522xBU-619 N/A No
Expand 2-ports, single source with configurable test
set, extended power range, and bias-tees to 4-ports
N522xB-220 N/A N522xBU-620 N/A No
Expand 2-ports, internal second source with
configurable test set, extended power range,
combiner, and mechanical switches to 4-ports
N524xB-222 N524xBU-622 N/A N/A No
Expand 2-ports, internal second source with
configurable test set, extended power range, bias-
tees, combiner, and mechanical switches to 4-ports
N524xB-224 N524xBU-623 N/A N/A No
Test set and power configuration
Add configurable test set, 2-ports N522xB-200 N/A N522xBU-201 N/A No
Add configurable test set and source attenuators,
2-ports
N523xB-200 N/A N/A N523xBU-216 No
Add low frequency extension, 2-ports N522xB/41/42B-201,
or N522xB-217, 219
N5241/42BU-205 N522xBU-205 (for
201), N522xBU-220
(for 217 or 219)
N/A No
Add extended power range, 2-ports
2
N522x/4xB-201 N524xBU-217 N522xBU-217 N/A No
Add bias-tees, 2-ports
2
N522x/4xB-217 or
N524xB-222
N524xBU-219 N522xBU-219 N/A No
Add extended power range and bias tees, 2-ports N5227/47B-201 N5247BU-219 N5227BU-219 N/A No
Add internal 2nd source, combiner and mechanical
switches, 2-ports
N524xB-217/219 N524xBU-224 N/A N/A No
PNA Family Network Analyzer Upgrade Kits
Frequency, test ports, test set and power configurations
Upgrade kits are available to add options after initial purchase. To upgrade the PNA-X/PNA/PNA-L, order the corresponding item number. The model and
serial numbers of the instrument to be retrofitted are required as part of the order. To add application software, order the appropriate standalone model
numbers shown in the tables on pages 7 and 8.

Keysight PNA-X Series Specifications

General

Output Power	+13 dBm (typical)
Number of Ports	2 or 4
Dimensions	426 mm (W) x 470 mm (D)
Power Requirements	100 to 240 VAC, 50/60 Hz
Frequency Range	10 MHz to 26.5 GHz (varies by model)
