General Accessories (Continued)
Comb generators
Two are required for NVNA. Also requires separate power supply.
– U9391C 10 MHz to 26.5 GHz comb generator
– U9391F 10 MHz to 50 GHz comb generator
– U9391G 10 MHz to 67 GHz comb generator
Amplifiers
– 83006A power amplifier, 10 MHz to 26.5 GHz, 20 dB gain,
power out: +18 dBm to 10 GHz or +16 dBm to 20 GHz or
+14 dBm to 26.5 GHz
– 83017A power amplifier, 50 MHz to 26.5 GHz, 25 dB gain,
power out: +20 dBm to 20 GHz, or +15 dBm to 26.5 GHz
– 83018A power amplifier, 2 to 26.5 GHz, 27 dB gain to 20
GHz or 23 dB to 26.5 GHz, power out: +24 dBm to 20 GHz or
+21 dBm to 26.5 GHz
– 83020A power amplifier, 2 to 26.5 GHz, 30 dB gain to
20 GHz or 27 dB to 26.5 GHz, power out: +30 dBm to 20 GHz
or +26 dBm to 26.5 GHz
Equipment rack accessories
– E3663AC Rail kit (included with Option 1CM and 1CP)
– 1CM042A Rack mount flange kit, for use without handles
(included with Option 1CM)
– 5063-1555 Rack mount flange kit with handles
(included with Option 1CP)
3
Monitors
Any VGA-compatible monitor can be connected directly to the
rear panel. Monitors with other video interfaces (for example,
HDMI or DisplayPort) require USB-based video adapters (must
be supplied by the user). Touch-screen monitors are supported.
Interface cables
Choose the appropriate cables to connect each peripheral to the
network analyzer.
– 10833A GPIB cable, 1.0 m (3.3 ft)
– 10833B GPIB cable, 2.0 m (6.6 ft)
– 10833D GPIB cable, 0.5 m (1.6 ft)
– 82357B GPIB to USB interface
– 83050A power amplifier, 2 to 50 GHz, 23 dB gain, power out:
+20 dBm to 40 GHz or +17 dBm to 50 GHz
– 83051A power amplifier, 45 MHz to 50 GHz, 23 dB gain
power out: +12 dBm to 45 GHz or +10 dBm to 50 GHz
Couplers
– 87300B coaxial coupler, 1 to 20 GHz, SMA (f), 10 dB
coupling
– 87300C coaxial coupler, 1 to 26.5 GHz, 3.5 mm (f), 10 dB
coupling
– 87301B coaxial coupler, 10 to 46 GHz, 2.92 mm (f), 10 dB
coupling
– 87301D coaxial coupler, 1 to 40 GHz, 2.4 mm (f) or optional
2.92 mm (f), 13 dB coupling
– 87301E coaxial coupler, 2 to 50 GHz, 2.4 mm (f), 10 dB
coupling
– 87310B 90
o
coaxial coupler, 1 to 18 GHz, SMA (f), 3 dB
coupling

Keysight PNA-X Series Specifications

General

Output Power	+13 dBm (typical)
Number of Ports	2 or 4
Dimensions	426 mm (W) x 470 mm (D)
Power Requirements	100 to 240 VAC, 50/60 Hz
Frequency Range	10 MHz to 26.5 GHz (varies by model)
