Keysight PNA-X Series Configuration Guide

Page 26
Find us at www.keysight.com
Overview S93029B/A without Option 029 S93029B/A with Option 029
Description Noise figure application using standard receivers
only, for all PNA/PNA-X models
Noise figure application using standard or low-noise
receivers, for all PNA-X models
Required options Not recommended with PNA Options 200, 210, 400,
410
For N5241/42/49B, one of Options 21x, 22x, 41x or 42x
For N5244/45/47B, one of Options 22x or 42x
Includes low-noise receiver No Yes
1
Includes filters for LO-harmonic
rejection
No Yes
1
Includes source tuner bypass switch No Yes
Use standard receivers for noise figure
measurements
2
Yes Yes
Vector noise calibration available using
ECal as tuner
Yes Yes
Vector noise calibration using built-in
tuner
No Yes, for N5244/45/47B
1
Recommended ECal for vector noise
calibration
3
3.5 mm N4691D-M0F (N5221/22/41/42/49B) 3.5 mm N4691D-M0F (N5241/42/49B)
2.4 mm N4693D-M0F (N5224/25/44/45B) Built-in for N5244/45/47B
1.85 mm N4694D-M0F (N5227/47B)
Included tuner accessories for m-f ECal 3.5 mm N5242-20169 cable, 85052-60013 m-f
adapter (N5221/22/41/42/49B)
2.4 mm N5245-20140 cable, 85056-60007 m-f
adapter
(N5224/25/44/45B)
1.85 mm N5247-20142 cable, 85058-60115 m-f
adapter (N5227/47B)
3.5 mm N5242-20169 cable, 85052-60013 m-f adapter
(N5241/42/49B)
N/A for N5244/45B, due to built-in tuner
1.85 mm N5247-20142 cable, 85058-60115 m-f
adapter (N5247B, for use with external 67 GHz ECal)
Recommended adapter for f-f ECal
tuner (N4691D/93D/94D-F0F)
3.5 mm 85052-60014 m-m adapter
(N5221/22/41/42/49B)
2.4 mm 85056-60005 m-m adapter
(N5224/25/44/45B)
1.85 mm 85058-60113 m-m adapter (N5227/47B)
3.5 mm 85052-60014 m-m adapter (N5241/42/49B)
N/A for N5244/45/47B, due to built-in tuner
Scalar noise calibration available Yes Yes
S-parameter, conversion gain/loss measurements
Max freq (GHz) 8.5/13.5/26.5/43.5/50/67 8.5/13.5/26.5/43.5/50/67
NF measurements, amplifiers
Max frequency, using low-noise
receivers (GHz)
N/A 8.5/13.5/26.5/43.5/50
Max frequency, using standard
receivers (GHz)
2
8.5/13.5/26.5/43.5/50/67 8.5/13.5/26.5/43.5/50
Calibration accessories for low-noise
receivers
N/A Cal kit or ECal, 346C or 346C-K01 noise source or
power meter
Calibration accessories for standard
receivers
Cal kit or ECal, power meter Cal kit or ECal, power meter
PNA Family Applications and Options (Continued)
Noise figure measurement summary
1. For N5247B, the low-noise receiver and tuner works up to 50 GHz only.
2. External preamplifier and filter(s) required if DUT excess noise (gain plus noise figure) is < 30 dB up to
20 GHz, < 40 dB up to 50 GHz, or < 45 dB up to 67 GHz.
3. Only N4690 Series ECal modules are supported for use as an impedance tuner.

Keysight PNA-X Series Specifications

General

Output Power	+13 dBm (typical)
Number of Ports	2 or 4
Dimensions	426 mm (W) x 470 mm (D)
Power Requirements	100 to 240 VAC, 50/60 Hz
Frequency Range	10 MHz to 26.5 GHz (varies by model)
