Keysight PNA-X Series Configuration Guide

Page 43
Find us at www.keysight.com
85093C-xxx mixed-connector options:
Port A option Port B option
Type (f) (m) Type (f) (m) Type (f) (m)
3.5 mm 101 102 Type-N 50 ohm 203 204 7-16 205 206
N4431B Microwave ECal: 300 kHz to 13.5 GHz, 4-ports. Includes:
– Option 010 module with: N4431-60006 4 x 3.5 mm (f) ECal
module
N4431B-xxx mixed-connector options:
Connector type Port A
option
Port B
option
Port C
option
Port D
option
3.5 mm (f) 101 201 301 401
3.5 mm (m) 102 202 302 402
Type-N 50 ohm (f) 103 203 303 403
Type-N 50 ohm (m) 104 204 304 404
7-16 (f ) 105 205 305 405
7-16 (m)
106
206 306
406
– Option 150: Replaces standard storage container with a
wooden box
N4433A Microwave ECal: 300 kHz to 20 GHz, 4-ports. Includes:
– Option 010 module with: N4433-60003 4 x 3.5 mm (f) ECal
module
N4433A-xxx mixed-connector options:
Connector type Port A
option
Port B
option
Port C
option
Port D
option
3.5 mm (f) 101 201 301 401
3.5 mm (m) 102 202 302 402
– Option 150: Replaces standard storage container with a
wooden box
N4691D
1
Microwave ECal: DC or 300 kHz to 26.5 GHz, 2-ports.
Includes:
– Option F0F: Both connectors are 3.5 mm female on module
– Option M0F: 1 female and 1 male 3.5 mm connector on
module
– Option M0M: Both connectors are 3.5 mm male on module
– Option 0DC: DC to 26.5 GHz
– Option 003: 300 kHz to 26.5 GHz
– Option 00A adds:
– 85052-60012 3.5 mm (f) to 3.5 mm (f) adapter
– 85052-60014 3.5 mm (m) to 3.5 mm (m) adapter
Cables
– 85131C
2
single, semi-rigid: 3.5 mm (f) to PSC-3.5 mm (f),
81 cm, 32 inches
– 85131D
2
set, semi-rigid:
– One 3.5 mm (f) to 3.5 mm (m), 53 cm, 21 inches, p/n
85131-60009
– One 3.5 mm (f) to PSC-3.5 mm (f), 53 cm, 21 inches,
p/n 85131-60010
– 85131E
2
single, flexible: 3.5 mm (f) to PSC-3.5 mm (f),
96.5 cm, 38 inches
– 85131F
2
set, flexible:
– One 3.5 mm (f) to 3.5 mm (m), 62.2 cm, 24.5 inches,
p/n 85131-60012
– One 3.5 mm (f) to PSC-3.5 mm (f), 62.2 cm, 24.5 inches,
p/n 85131-60013
– 85131H
2
single, flexible: 3.5 mm (f) to 3.5 mm (m), 62.2 cm,
24.5 inches
– 85134E
2
single, flexible: PSC-3.5 mm (f) to 2.4 mm (f),
96 cm, 38 inches
– 85134F
2
set, flexible:
– One 2.4 mm (f) to PSC-3.5 mm (f), 53 cm, 21 inches,
p/n 85134-60004
– One 2.4 mm (f) to PSC-3.5 mm (m), 53 cm, 21 inches,
p/n 85134-60003
– 85134H
2
single, flexible: 2.4 mm (f) to PSC-3.5 mm (m),
53 cm, 21 inches
– N4419AK20 single, flexible: 3.5 mm (m) to 3.5 mm (f),
91.4 cm, 36 inches
– Z5623A-K20 single, flexible: 3.5 mm (m) to 3.5 mm (m),
91.4 cm, 36 inches
Adapter sets
– 85130D 3.5 mm
2
to 3.5 mm
1. The PNA Series must have firmware revision A.12.85.00 or above for the
operation with the N469xD Series ECal.
2. Special rugged female connector specifically for connecting to the
network analyzer test port, but does not mate with a standard male
connector.
N4691B Microwave ECal: 300 kHz to 26.5 GHz, 2-ports.
Includes:
– Option M0F module with: N4691-60004 3.5 mm (f) to
3.5 mm (m) ECal module
– Option 00M module with: N4691-60005 3.5 mm (m) to
3.5 mm (m) ECal module
– Option 00F module with: N4691-60006 3.5 mm (f)
to 3.5 mm (f) ECal module
– Option 00A adds:
– 85052-60012 3.5 mm (f) to 3.5 mm (f) adapter
– 85052-60014 3.5 mm (m) to 3.5 mm (m) adapter
– Option 150: Replaces standard storage container with a
wooden box

Keysight PNA-X Series Specifications

General

Output Power	+13 dBm (typical)
Number of Ports	2 or 4
Dimensions	426 mm (W) x 470 mm (D)
Power Requirements	100 to 240 VAC, 50/60 Hz
Frequency Range	10 MHz to 26.5 GHz (varies by model)
