Keysight PNA-X Series Configuration Guide

Page 8
Find us at www.keysight.com
Application software
1
(Continued)
The S93xxxB software products replace the S93xxxAs, and the S93xxxAs will be discontinued in June 2019.
Description For PNA-X
Series
For PNA
Series
For PNA-L
Series
Additional information
Spectrum analysis, up to 8.5 GHz
2
S930900B/A S930900B/A S930900B/A
Spectrum analysis, up to 13.5 GHz
2
S930901B/A S930901B/A S930901B/A
Spectrum analysis, up to 26.5 GHz
2
S930902B/A S930902B/A S930902B/A
Spectrum analysis, up to 43.5 GHz
2
S930904B/A S930904B/A S930904B/A
Spectrum analysis, up to 50 GHz
2
S930905B/A S930905B/A S930905B/A
Spectrum analysis, up to 67 GHz
2
S930907B/A S930907B/A N/A
Spectrum analysis, up to 90 GHz
2
S930909B/A S930909B/A N/A
Spectrum analysis, up to 120 GHz S93093B/A S93093B/A N/A
Spectrum analysis, beyond 120 GHz S93094B/A S93094B/A N/A
Active hot parameters S93110B/A N/A N/A Requires a 4-port test set option (4xx)
Low-frequency extension (LFE) is disabled with Option 425
Active hot parameters S93111B/A N/A N/A Export-restricted version for N5247B with maximum operation
to 50 GHz
Requires a 4-port test set Option (4xx)
Low-frequency extension (LFE) is disabled with Option 425
Fast CW measurements S93118B/A S93118B/A N/A
True-mode stimulus S93460B/A S93460B/A N/A Requires a 4-port test set option (4xx)
N-port measurements
3
S93551B/A
4
S93551B/A S93551B/A Not available with test set options 200, 210, 400, and 410
Nonlinear vector network analysis
5
Nonlinear component characterization S94510A
6
N/A N/A Requires test set option 41x or 42x
Nonlinear component characterization S94511A
6
N/A N/A Export-control version. Requires test set option 41x or 42x
Nonlinear X-parameters
8, 9
S94514A
7
N/A N/A Requires test set option 42x and application software S94510A
or S94511A
Nonlinear pulse-envelope domain S94518A N/A N/A Requires hardware option 021 and application software
S94510A or S94511A, and S93025B/A or S93026B/A
Arbitrary load-impedance X-parameters
8, 9
S94520A N/A N/A Requires application software S94514A and an additional
load-control application
Arbitrary load-control X-parameters
8, 9, 12
S94521A N/A N/A Requires application software S94520A
Arbitrary load-control device characterization
10, 11, 12
S94522A N/A N/A Requires application software S94510A or S94511A
1. The S9xxxxA software license types are fixed-perpetual (1FP), transportable-perpetual (1TP), fixed-1-year (1FY), and transportable-1-year (1TY). The S93xxxB software
has four license types: Node-locked, Transportable, USB Portable and Floating/Network, and has four term choices for each perpetual and time-based types. Please refer
to “Keysight Software Licensing Options, Provide Flexibility and Support” on page 29 for more details. (Note: S93093B/A, S93094B/A, S93898B/A, S93110B/A, S94510A
and S94511A have fixed-license types only). The fixed-perpetual (1FP) is the only license type that can be ordered as part of the instrument and installed. The other license
types must be ordered separately and installed from the web after the receipt of the instrument.
2. For use with PNA or PNA-X models, a test set with internal receiver attenuators is recommended to avoid receiver compression when measuring large input signals. For
use with PNA-L models, test set option 216 or 416 is recommended so that external attenuators can be connected via the front-panel jumpers to avoid receiver compression
as needed.
3. When ordering a test set, select an appropriate interface kit. Refer to Multiport Measurements section on page 32 for more details.
4. When N524xB is configured as a multiport analyzer using S93551B/A and a multiport test set, the combiner feature of Option 22x or 42x is temporarily disabled.
When configured as a standalone analyzer, the combiner feature is enabled.
5. A fully configured NVNA system requires two comb generators with power supplies, Keysight calibration kits (mechanical or ECal), and a power meter and sensor or USB
power sensor.
6. Pulse capability requires option 021 and S93025B/A or S93026B/A.
7. Pulse capability requires option 021, 022 and S93025B/A or S93026B/A.
8. Requires EXG, MXG, or PSG signal generator for X-parameter extraction (the PNA-X’s 10 MHz reference output can be used for 10 MHz tone-spacing applications).
9. X-parameters is a trademark and registered trademark of Keysight Technologies in the U.S., Europe, Japan, and elsewhere. The X-parameters format and underlying
equations are open and documented. For more information, visit www.keysight.com/find/eesof-x-parameters-info.
10. Currently CW stimulus only.
11. Use of this application will generally require external sources, couplers attenuators, wafer probe station and more to complete system configuration. Please work with your
local Keysight application engineer for details.
12. Requires Win 7 OS or above.
PNA Family Network Analyzer Configurations (Continued)
PNA-X Series PNA Series PNA-L Series Test Port Connector
N5249B 900 Hz/10 MHz to 8.5 GHz N5239B 300 kHz to 8.5 GHz 3.5 mm (male)
N5241B 900 Hz/10 MHz to 13.5 GHz N5221B 900 Hz/10 MHz to 13.5 GHz N5231B 300 kHz to 13.5 GHz 3.5 mm (male)
N5242B 900 Hz/10 MHz to 26.5 GHz N5222B 900 Hz/10 MHz to 26.5 GHz N5232B 300 kHz to 20 GHz 3.5 mm (male)
N5244B 900 Hz/10 MHz to 43.5 GHz N5224B 900 Hz/10 MHz to 43.5 GHz N5234B 10 MHz to 43.5 GHz 2.4 mm (male)
N5245B 900 Hz/10 MHz to 50 GHz N5225B 900 Hz/10 MHz to 50 GHz N5235B 10 MHz to 50 GHz 2.4 mm (male)
N5247B 900 Hz/10 MHz to 67 GHz N5227B 900 Hz/10 MHz to 67 GHz 1.85 mm (male)

Keysight PNA-X Series Specifications

General

Output Power	+13 dBm (typical)
Number of Ports	2 or 4
Dimensions	426 mm (W) x 470 mm (D)
Power Requirements	100 to 240 VAC, 50/60 Hz
Frequency Range	10 MHz to 26.5 GHz (varies by model)
