Kia K5 2021 - Instrument Cluster; Instrument Cluster Overview

0
20
40
60
80
100
120
140
160
180
200
220
240
260
0
1
2
3
4
5
6
7
8
km/h
EPB
C
H
x1000rpm
0
20
40
60
80
100
120
140
160
E
F
MPH
(Type A cluster)
This illustration is for demonstration purposes only. Some indicators and warning lights
may not appear in illustration. On the vehicle, they may appear in the LCD.
Your vehicle’s instrument cluster & indicator light locations may differ from those in the
illustrations. See Section 4 in the Owner’s Manual for more information.
A
B B
C
D
E
E
F
G
Instrument Cluster Overview
A
Tachometer
B
Turn Signal Indicators
C
Speedometer
D
Engine Temperature Gauge
E
Indicators & Warning Lights
F
LCD – Gear Shift Position, Odometer,
Trip Modes / Trip Computer,
Driving Assist
G
Fuel Gauge
Arrow direction indicates the side of
the vehicle the fuel door is located
3
ALWAYS CHECK THE OWNER’S MANUAL FOR COMPLETE OPERATING INFORMATION AND SAFETY WARNINGS. *IF EQUIPPED
INSTRUMENT CLUSTER
INSTRUMENT
CLUSTER
