0
20
40
60
80
100
120
140
160
180
200
220
240
260
0
1
2
3
4
5
x1000rpm
0
20
40
60
80
100
120
140
160
E
F
MPH
Tire Pressure Monitoring
System Video
To view a video on your
mobile device, snap this
QR Code or visit the listed
website.
Refer to inside front cover
information.
www.youtube.com/KiaFeatureVideos
QR CODE
(Indicator located on Instrument Cluster)
Tire Pressure Monitoring System (TPMS)
†24
The TPMS indicator functions as both Low Tire Pressure Light
and TPMS Malfunction Indicator
A
. The indicator is designed
to illuminate if it detects one or more tires is significantly underinflated,
the vehicle has a spare tire installed without TPMS or the outside
temperature becomes significantly lower.
The Low Tire Pressure Position Indicator
B
is displayed on the LCD
screen in the Instrument Cluster when the tire(s) is underinflated. Inflate
tire(s), using an accurate digital tire pressure gauge, to specifications to
turn off the Low Tire Pressure Position Indicator
B
; see the front driver’s
door jamb for PSI specification.
When there is a problem with the TPMS, the TPMS Malfunction Indicator
will blink for approximately one minute and then illuminate–see dealer
for service.
• Even with TPMS, tire pressure should be checked manually at least once a month. Only adjust tire pressure on “cold tires”
that have been sitting for 20 minutes, and tires that are not hot in temperature from direct sunlight or heat
• For proper maintenance and optimal fuel economy, maintain recommended tire inflation pressures and stay within the
load limits and weight distribution recommended for your vehicle
• In winter or cold weather, the TPMS light may illuminate if the tire pressure was adjusted to the recommended tire
inflation pressure during warm weather
QUICK TIPS
REMINDERS:
• Check the recommended tire pressure label located on the left side of driver's door jamb, which is visible when the door is open
• Consult your dealer for service if the Low Tire Pressure Light remains illuminated after inflating your tire(s)
• Personal electronic devices (such as laptops, wireless chargers, remote start systems, etc.) can interfere with the TPMS system,
which may cause the Malfunction Warning Indicator (Check Engine Light) to illuminate
For illustrative purposes only. Your actual display, buttons and/or features may vary. Refer to section 6 in the Owner’s Manual for more information.
5
ALWAYS CHECK THE OWNER’S MANUAL FOR COMPLETE OPERATING INFORMATION AND SAFETY WARNINGS. *IF EQUIPPED †LEGAL DISCLAIMERS ON BACK INSIDE COVER
A
INSTRUMENT CLUSTER
INSTRUMENT
CLUSTER
Tire Pressure
3525
35
psi
35
B
To Next Page
