SRA Smart Reflow Analyzer Hardware Guide SRA-330200-000
13
6. Click the radio button for Transmitter,
followed by the Save (green check) button
7. Click OK on the message boxes. You will then
be returned to the main screen.
8. Remove the USB cable from the SRA and insert
it into the Smart Dock.
9. Tap the Smart Dock and then cover either one of
the two (2) SRA speed sensor windows on top
of the SRA for at least 5 seconds to start the
pairing.
10. The ANT blue LED on both devices flashes
until the devices are paired.
11. The Wi-Fi orange LED on both devices flashes
every 3 seconds indicating a successful Wi-Fi
connection.
