5.1 ZONE
Upon selection the display will show two options which are available within this menu
as shown in figure 4.2. The required option can be highlighted by operation of either
the relevant numeric key or by operation of the arrow keys. When the selection is
correct operation of the Enter key will then enter the highlighted selected option.
Access Level 2 List zones
All zones
Zone information
Select option using
↑ ← and
↵
Figure 4.2
All Zones
This option selection will list all of the zone information, the listing will give the zone
number, zone text and the status i.e. if the zone is isolated “I” as shown in figure 4.3.
Access level 2 List zones
Zone 011 Store Room Area Bld 6
Zone 012 Goods Receive Area
Zone 013 Computer Suite
Zone 014 Product Inspection Area
Zone 015 General Administration
Zone 016 Main Reception Area
↑
to scroll and → to quit
Figure 4.3
Operation of the arrow keys will scroll the zone information and operation of the
Cancel key will return the display through the menu selections and continued
operation will return the panel to access level 1.
