Kidde Vega

TM0024 Page 27 of 33 Issue 2.01
Operation of the arrow keys will scroll the information on the display. When viewing
is complete operation of the Cancel key will quit the display to the menu and
continued operation will return the panel to access level 1.
5.4 PANEL FUNCTIONS
Selection of this option will list the information which has been programmed to the
sounder circuits and relay outputs of the master and slave basic loop controllers as
shown in figure 4.10.
Access Level 2 List
Mblc Scct-2 Production area sounder
Mblc Scct-3 Reception area sounder
Mblc Scct-4 Gate House Signal
Mblc vfco-1 Unassigned
Mblc vfco-2 Reception Indicator
Mblc vfco-3 Production HVAC relay
↑ to scroll, → to quit
Figure 4.10
Operation of the arrow keys will scroll the information on the display. When viewing
is complete operation of the Cancel key will quit the display to the menu and
continued operation will return the panel to access level 1.
5.5 PLANT
Operation of this option is similar to that of the List Zone menu selection as explained
in section 5.1, the only difference is the Zone text will be replaced with “Plant”.
5.6 ISOLATIONS
Upon selection the display will show another set of sub menu options as shown in
figure 4.11. The required option can be highlighted by operation of the either the
relevant numeric key or by operation of the arrow keys. When the selection is correct
operation of the Enter key will then enter the highlighted selected option.
Access Level 2 List isolations
Zones Plant
Loop Devices
Output Groups
Panel Functions
Select option using ↑ ← &
↵
Figure 4.11
Selection will list all of the current isolations on the control panel for that particular
option position. By operation of the arrow keys the information will be scrolled on the
display. When viewing is completed operation of the Cancel key will quit the display
to the menu and continued operation will return the panel to access level 1.
