TM0024 Page 24 of 33 Issue 2.01
Zone Information
Upon selection a request for the zone number will be made, once selected the zone
information, zone number, zone text and the device information will be displayed as
shown by figure 4.4. The displayed device information is for the devices, which have
been assigned to the selected zone.
Access level 2 List zones
Zone 011 Store Room Area Bld 6
T1 00s T2 000s override: BGU YES DK NO
D008.1 Loop 01 Zone 011 Status I
I/O Unit Emergency Door Closer
D011.1 Loop 01 Zone 011
Optical Stores Office Area
↑ to scroll and
→ to quit
Figure 4.4
The Zone information will include the timer settings for T1 and T2, operation of the
arrow keys will scroll the device information only. The device information includes
the current status of the devices listed. Operation of the arrow keys will scroll the
device information and operation of the Cancel key will return the display through the
menu selections and continued operation will return the panel to access level 1.
5.2 LOOP DEVICES
Upon selection of this menu option a list of two sub menu options will appear which
are capable of being selected as shown in figure 4.5.
Access level 2 List loop devices
Single loop
Device range
Select option using ↑ ← &
↵
Figure 4.5
These sub menus feature can be selected by operation of either the arrow keys or by
operation of the corresponding numeric key and confirming the selection by operation
of the ENTER key.
