TM0024 Page 15 of 33 Issue 2.01
CHAPTER 4
ISOLATE MENU OPTIONS
4. ISOLATE MENU
The entry into access level 2 is explained in section 3.2, upon the selection of the
ISOLATE menu feature it will be possible to select from the sub menu features as
shown in figure 3.0. These sub menus can be selected by operation of either the
arrow keys or by operation of the corresponding numeric key and confirming the
selection by operation of the Enter key (
↵
).
Access Level 2 Isolate
Zones Plant
Loop devices
Output group
Panel functions
Select option using ↑ ←
and
↵
Figure 3.0
4.1 ZONES
To isolate a specific zone, a zone number is required to be entered at the prompt,
once selected the display will list the zones starting from the requested zone number
as shown in figure 3.1.
Access level 2 Isolate
Zone 011 Store Room Area Bld. 6 Norm
Zone 012 Goods Receive Area Bld 6 Norm
Zone 013 General Despatch Area Norm
Zone 014 Product Inspection Area Norm
Zone 015 General Administration Norm
Zone 016 Main Reception Area Norm
Select option using ↑ &
↵
Figure 3.1
