TM0024 Page 9 of 33 Issue 2.01
3.2 ACCESS
The Repeater panel with controls has 2 separate access levels with access level 1
being available to the user without entry of any special password. Each access level
has its own operating criteria as shown in Table 2.0, which restricts operation of the
panel by the user. The level 2 password is identical to that set within the main control
panel and is accessed in the same manner and only access level 2 maybe entered
from a type 2 repeater panel.
When the main control panel is in access level 2 or 3 all of the repeaters connected
onto the system are given a lock out message. While the repeater panels are locked
out the LCD displays a message indicating the lockout, as shown in figure 2.0. Once
the main panel takes control of the system it is not possible to access the system
from any of the repeater panels.
STATUS
Sat 30 Mar
96
NORMAL
Main panel in access
Figure 2.0
When a repeater panel takes control of the system the LCD on all panels attached to
the systems will display a lock out message as shown in figure 2.1. The information
shows the address number of the repeater and the 24 characters of user text (which
is used to determine the location) for the repeater, which has taken control of the
system.
STATUS
Sat 30 Mar
96
NORMAL
System controlled by repeater 02
EAST SIDE GATE HOUSE
Figure 2.1
