5.3 OUTPUT GROUPS
Selection of this option a list of two menu options will appear, as shown in figure 4.8.
The required option can be highlighted by operation of the arrow keys and when
correct the Enter key will enter the selected option menu.
Access level 2 List output groups
All groups
Group Information
Select option using ↑ &
↵
figure 4.8
All Groups
When selected the display will request for a start and end group number to be
selected by use of either the arrow or numeric keys and operating Enter when the
selection is complete. Once selected the display will list the group information which
has been programmed into the control panel. Operation and display is similar in
format to the List All Zones option as in section 5.1.1. The main difference is that the
zone text is replaced with “Group” text.
Operation of the arrow keys will scroll the information on the display. When viewing is
complete operation of the Cancel key will quit the display to the menu and continued
operation will return the panel to access level 1.
Group Information
When selected this will list the group information which has been programmed in the
control panel as shown in figure 4.9. Operation and display is similar in format to the
List Zones Information option as in section 5.1.2. The main difference is that the
zone text is replaced with “Group” and all the output devices assigned to the selected
output group will be listed.
Access level 2 List output groups
Group 001 Production activations
T3 010s override Y T4 020m override Y
Action on program Evacuate No
Deactivate on silence alarms
D010.1 Loop 01
Mblc Scct1
↑ to scroll, → to quit
Figure 4.9
