Genesis EG1 Series
Wall Strobes,
Horns & Chimes
SUBMIT
VM
Notification Appliances
SERIES
Genesis strobes offer 15 to 110 candela output, which is selectable with a conveniently-located switch on the side of the
device. The candela output setting remains clearly visible even after final installation, yet it stays locked in place to prevent
unauthorized tampering. (Data Sheet K85001-0573)
White housing White housing Red housing Red housing Fire Alarm Appliances
no marking with “FIRE” no marking with “FIRE” (with “Running Man” icon)
EG1-VM EG1F-VM EG1R-VM EG1RF-VM Strobe only (15/30/75/110 cd)
EG1F-V1575 EG1RF-V1575 Strobe only (15/75 cd¹), 24 V
Genesis Horns and Horn-strobes reach output levels as high as 99 dB and features a unique multiple frequency tone that
results in excellent wall penetration and an unmistakable warning of danger. Horns may be configured for either coded or non-
coded signal circuits. They can also be set for low dB output with a jumper cut that reduces horn output by about 5 dB.
(Data Sheet K85001-0573)
White housing White housing Red housing Red housing Fire Alarm Appliances
no marking with “FIRE” no marking with “FIRE” (with “Running Man” icon)
EG1-HD EG1F-HD EG1R-HD EG1RF-HD Horn only (high/low dB)
EG1-HDVM EG1F-HDVM EG1R-HDVM EG1RF-HDVM Horn-strobe (15/30/75/110, high/low dB)
EG1F-HDV1575 EG1RF-HDV1575 Horn-strobe (15/75 cd¹, high/low dB), 24 V
EG1-P EG1F-P EG1R-P EG1RF-P Steady horn (not compatible with Signal Master)
Genesis mass notification appliances bring the same high-performance fire alarm features and unobtrusive design to
mass notification applications. Available with amber lenses and optional “ALERT” housing labels, they are ideal for applica-
tions that require differentiation between fire alarm and mass notification alerts. (Data Sheet K85001-0573)
White housing White housing Mass Notification Appliances
no marking with “ALERT” (with no “Running Man” icon)
G1WN-VMA G1WA-VMA Strobe only, amber lens (A/B/C/D cd settings)
G1WN-VMC G1WA-VMC Strobe only, clear lens (15/30/75/110 cd)
Genesis chimes and chime-strobes produce a pleasing mellow tone. When steady (non-stroked) voltage is applied, the
chime automatically pulses at 60 strokes per minute, or may be field-configured for temporal output. When installed with
a GIM Signal Master Module, the chime may also be field-configured for coded operation. Chimes may be set for low dB
output with a jumper cut that reduces sound output by about 5 dB. (Data Sheet K85001-0574)
White housing White housing Red housing Red housing Fire Alarm Appliances, high/low dB
no marking with “FIRE” no marking with “FIRE” (with “Running Man” icon)
EG1-C EG1F-C EG1R-C EG1RF-C Chime only
EG1-CVM EG1F-CVM EG1R-CVM EG1RF-CVM Chime-strobe (15/30/75/110)
Trim plates for wall horns, chimes, and strobes are ideal for covering openings left behind during retrofits.
White plate White plate Red plate Red plate White plateFire Trim Plates
no marking with “FIRE” no “FIRE” with “FIRE” with “ALERT”
EG1T EG1T-FIRE EG1RT EG1RT-FIRE G1WT-ALERT Trim plate for 2-gang or 4” boxes
¹ 15/75 cd models provide fixed output. The 15 cd output component complies with UL1971. The 75 cd output component complies with UL 1638.
Genesis signals feature textured housings in architecturally neutral white or
traditional fire red. An ingenious iconographic symbol indicates the purpose
of the device. This universal symbol is code-compliant and is easily recog-
nized by all building occupants regardless of what language they speak.
models with “FIRE” and “ALERT” markings are also available.
