Kidde VM-1R User Manual

VM Series
Head End
8
SUBMIT

VM
Head End
SERIES
VM Series features an extra-large backlit display with
a full 24-line by 40 character screen capable of show-
ing eight simultaneous events without the need from
scrolling. Up to three switch/LED strips may be
added, with control operations and multi-colored LED
behavior controlled by software. Customizable inserts
provide plenty of room for meaningful labels, while
large tactile control buttons instill confidence and
promote quick response when time is of the essence.
The main display mounts to the CPU. Control/display
modules attach to a convenient mounting frame.
Control Display Modules
VM Control Display Modules provide additional operator interface capability. The
module consists of 12 groups of two LED-switches arranged as a quad-color LED
that is software programmable to amber, red, blue, or green, and a single-color
amber LED.
D12LS-VM Control/Indicating Display Strip, 12 groups: two LEDs with switch. Data Sheet K85005-0133
FireWorks Graphical Annunciation Interface
The FireWorks Graphical Annunciation Interface is a software platform that provides end us-
ers with clear, concise, and coordinated site incident information. FireWorks also supports
optional text-based web clients to provide remote status updates. Five congurable graphical
viewports oer simultaneous insight into dierent aspects of an incident, while the underlying
software dynamically manages content in each viewport based on real-time events and user
interaction. Facility maps, embedded HTML viewer, and live event ow from vital equipment
all come together instantly within view of an operator facing events that require solid informa-
tion and split-second timing.
FW-CGSVM FireWorks Graphics Software. Fiveviewport display. No common control. Data Sheet K85005-0068
FW-IPMON1000 IP Monitoring, 1000 connections. Requires FW-DARCOM. Data Sheet K85005-0068
FW-DARCOM For Communication to DACRs and/or IPMON1000. Data Sheet K85005-0068
24VDC FROM 3-PPS/M
OR 3-BPS/M POWER RISER
FROM PREVIOUS PANEL
RS-485 NETWORK DATA
POWER MODULE
RS-485 NETWORK DATA
TO NEXT PANEL
24VDC TO NEXT
LED-based Graphic Annunciation
The GCI series of graphic annunicator drivers allow the VM control panel to display events
on an LED-based graphic annunciator. The GCI annunciator card supports 32 LEDs on the
graphic panel display. It includes status LEDs and an internal buzzer. The graphic card is
supplied with snap track mounting. It is attached to a plastic mounting rail that requires two
EIA panels. The annunciator communicates with the control panel on the RS 485 data riser,
which can be congured for Class A or Class B communication. Always ensure that National
and Local approvals and requirements are met when selecting a graphic panel supplier.
GCI Graphic Annunciator Driver. Data Sheet K85005-0133
GCIX Graphic Annunciator Driver Expander. Outputs for 48 LEDs, 24 switch inputs. Data Sheet K85005-0133
Control, Display
& Annunciation
A
LL
F
LO
OR
S
E
V
A
C
A
L
L
FL
O
O
R
S
A
L
ER
T
F
L
O
O
R
1
A
L
E
RT
F
L
O
O
R
1
E
V
A
C
FL
O
O
R
2
A
L
E
R
T
F
L
O
O
R
2
E
V
A
C
F
L
O
O
R
3
A
L
E
R
T
FL
O
O
R
3
E
V
A
C
F
L
O
O
R
1
S
L
O
W
W
O
O
P
F
L
O
O
R
2
S
LO
W
W
O
O
P
F
L
O
O
R
3
S
L
OW
W
O
O
P
A
L
L
F
L
O
O
R
S
F
A
S
T
W
O
O
P

Kidde VM-1R Specifications

General

Brand	Kidde
Model	VM-1R
Category	Control Panel
Language	English
