Network Options
Fiber Optic Transceivers
VM-NOCF Fiber
Network Module
Transceivers
Fiber Optic Transceivers are used with a ber optic network module to provide transmission
and reception capability over ber optic cable for re control panels. Class B, Class A or Class X
congurations are supported.
SMXLO2 Standard output single-mode for up to 8.7 mi. (14 km) node-to-node. Data Sheet K85005-0133
SMXHI2 High output single-mode for up to 24.85 mi. (40 km) node-to-node. Data Sheet K85005-0133
MMXVR Standard output multimode for up to 8,000 ft. (2.4 km) node-to-node. Data Sheet K85005-0133
VM-NOCF Fiber Network Option Module
VM-CPU
Main Board
VM-NOCF
Fiber Network
Option Module
The VM-NOCF Fiber Network Option Module provides a ber optic, or combination ber optic
and RS-485 communication path, for VM-1 control panels.
VM-NOCF Fiber Network Option Module. Uses MMXVR, SMXH2, SMXLO. Data Sheet K85005-0133
VM-NOC RS-485 Network Option Card
VM-CPU
Main Board
VM-NOC RS-
485 Network
Option Card
The VM-NOC RS-485 Network Option Card is used to connect up to eight VM-1 panels. The
card enables two independent RS-485 circuits for network data and digital audio communica-
tions. Class B and Class A wiring is supported.
VM-NOC Network Option Card, RS485, Class B or Class A wiring. Data Sheet K85005-0133
Audio Options
VM-PMI Paging Microphone Interface
The VM-PMI Paging Microphone Interface provides controls for emergency voice/
alarm communication and two-way reghters’ telephone communication. The VM-
PMI consists of an audio mounting bracket, EAEC Emergency Audio Evacuation
Controller card, enclosure, and paging microphone.
VM-PMI Audio Control & Paging Interface. Data Sheet K85005-0133
VM-MFK Master Fireghters’ Telephone
VM-MFK Master Firefighters’ Telephones add two-way firefighters’ telephone
capability to a VM-PMI Paging Microphone Interface. The VM-MFK mounts to the
VM-PMI. Together they comprise the re command center.
VM-MFK Master Fireghters’ Telephone Kit. Data Sheet K85005-0133

Kidde VM-1R Specifications
