Remote Booster Power Supply
The Remote Booster Power Supply is a self-contained 24 Vdc power supply designed
to augment re alarm audible and visual power requirements as well as provide power
for auxiliary, access control and security applications. The booster contains all of
the necessary circuits to monitor and charge batteries, control and supervise four
Class B or two Class A NAC circuits and monitor two controlling inputs from external
sources. It also provides the ability to synchronize Genesis series strobes to UL 1971
requirements, and oers independent horn control over two wires.
For comprehensive conguration and wiring details, refer to the BPS Application Guide, 85001-0582.
MIRBPS6A 6.5 Amp Booster Power Supply Data Sheet K85005-0125
MIRBPS6A/230 6.5 Amp Booster Power Supply (220V) Data Sheet K85005-0125
MIRBPS10A 10 Amp Booster Power Supply Data Sheet K85005-0125
MIRBPS10A/230 10 Amp Booster Power Supply (220V) Data Sheet K85005-0125
Power Supplies
