Kikusui PMC 18-5A - Operating as Constant Voltage Supply; Operating as Constant Current Supply

40 PMC-A
4.2 Using the Power Supply as a Constant
Voltage Power Supply
Output Setup Procedure
1. Check that the OUTPUT switch is off and turn on the
POWER switch.
2. While holding down the LIMIT switch, set the appro-
priate current for the load using the CURRENT knob.
The value entered here becomes the current limit.
3. While holding down the LIMIT switch, set the
required voltage using the VOLTAGE knob.
4. Turn on the OUTPUT switch.
C.V LED lights indicating that the power supply is in constant
voltage operation.
• If the output current exceeds the current limit that was
specified in step 2 due to load fluctuations when the
power supply is operating in constant voltage mode, the
power supply switches to constant current mode. When
the power supply switches to constant current mode, C.C
LED lights up.
4.3 Using the Power Supply as a Constant
Current Power Supply
Output Setup Procedure
1. Check that the OUTPUT switch is off and turn on the
POWER switch.
2. While holding down the LIMIT switch, set the allow-
able voltage using the VOLTAGE knob.
The value entered here becomes the voltage limit.
