Kikusui PMC 18-5A - Functions During Master-Slave Parallel Operation - -46

46 PMC-A
4.6.1 Functions during Master-Slave Parallel Opera-
tion
The functions of the PMC-A during master-slave parallel oper-
ation are as follows.
■ Voltmeter and Ammeter
For the total output current, sum the currents of the master and
slave units.
■ Remote Sensing
Available only on the master unit.
■ External Control
Available only on the master unit.
■ External Monitoring
• External monitoring of output voltage (V MON)
Can be monitored on the master unit.
• External monitoring of output current (I MON)
The output current of each master and slave units can be
monitored. For the total output current, sum the monitor val
-
ues of the master and slave units.
• Status monitors
The status of the constant voltage operation (CV STATUS),
constant current operation (CC STATUS), output on, and
POWER switch on can be monitored on each master and
slave units.
・Do not connect the common wires of the master and
slave monitors outside of the PMC-A. If the wire
connecting the load comes loose, the common wire
will break.
CAUTION
