Kikusui PMC 18-5A - Specifications (Type II Models)

80 PMC-A
7.2 Specifications (Type II)
Type II
PMC
18-5A
PMC
35-3A
PMC
70-1A
PMC
110-
0.6A
PMC
160-
0.4A
PMC
250-
0.25A
PMC
350-
0.2A
PMC
500-
0.1A
Input specifications
Input power
100 VAC ± 10 %, 50/60 Hz, single phase
(117 V, 200 V, 217 V, and 234 V are factory option)
Power consumption *1
(Max)
Aprx.
230 VA
(280
VA)
Aprx.
240 VA
(280
VA)
Approx. 150 VA
(190 VA)
Aprx.
110 VA
(140
VA)
Inrush
current
Peak current
70 A to 80 A 30 A to 50 A
Half value width
5 ms
Output specifications
Voltage
Rated voltage
18V 35V 70V 110V 160V 250V 350V 500V
Variable range
0 V to
18 V
0 V to
35 V
0 V to
70 V
0 V to
110 V
0 V to
160 V
0 V to
250 V
0 V to
350 V
0 V to
500 V
Constant voltage characteristics
Resolution
(Calculated
value) *2
3.3
mV
6.3
mV
12.6
mV
19.8
mV
28.8
mV
45.0
mV
63.0
mV
90.0
mV
Preset knob
turns
10 turns
Source effect *3
1 mV 3 mV 5 mV 7 mV 10 mV 15 mV 25 mV 30 mV
Load effect *4 5 mV 4 mV 5 mV 7 mV 10 mV 15 mV 25 mV 30 mV
Transient
response (stan
-
dard value) *5
50 µs 100 µs
Ripple noise
(RMS) *6
500 µV 1 mV 2 mV 3 mV 5 mV 10 mV
Full-load rise
time (TYP) *7
80 ms 450 ms 60 ms 50 ms 150 ms 100 ms 140 ms 190 ms
No-load fall
time (TYP) *8
330 ms 380 ms 260 ms 270 ms 220 ms 100 ms 90 ms 90 ms
Temperature
coefficient
100 ppm/ °C (TYP)
