Specifications
*1 At 100VAC rated load.
*2 A value calculated from the number of windings of the variable resistor. In the ac-
tual case, take 3 times to 5 times this value as a guide line.
*3 With respect to ± 10 % of the line voltage.
*4 With respect to 0 % to 100 % of the output current.
*5 The time it takes for the output voltage to recover within 0.05 % + 10 mV of the
rating when the output current fluctuates in the 10 % to 100 % range.
*6 At a measurement frequency bandwidth of 5 Hz to 1 MHz.
*7 The time it takes for the output voltage to rise from 10 % to 90 % of the rating
when the output is turned on.
*8 The time it takes for the output voltage to fall from 90 % to 10 % of the rating when
the output is turned off.
*9 J2 connector on the rear panel.
*10 Photocoupler open collector output. Maximum voltage 30 V, maximum current
(sink) approx. 5 mA. Insulated from the output and control circuits. Status signals
are not mutually insulated.
*11 See the rating of the fuse in the specification of “Protection function”.
Type I
PMC
18-1A
PMC
18-2A
PMC
18-3A
PMC
35-0.5A
PMC
35-1A
PMC
35-2A
General
Weight Approx.
3.5 kg
(7.72 Ib)
Approx.
4.0 kg
(8.82 Ib)
Approx.
5.0 kg
(11.02 Ib)
Approx.
3.5 kg
(7.72 Ib)
Approx.
4.0 kg
(8.82 Ib)
Approx.
5.0 kg
(11.02 Ib)
Dimensions See Fig. 7-1
Accessories
Operation manual 1 pc.
Power cord 1 pc.
Analog remote con-
trol contact
20 pcs.
Analog remote con-
trol plug
1 pc. (attached to the J2 connector on the rear panel)
Lock lever 1 pc. (attached to the analog remote control plug)
Fuse *11 1 pc.
