Basic Operation
C.V LED lights on the master power supply panel.
■ End procedure
1. Turn off the OUTPUT switch on the master power
supply.
2. Turn off the OUTPUT switch on the slave power sup-
plies.
3. Turn off the POWER switch on the slave power sup-
plies.
4. Turn off the POWER switch on the master power
supply.
When the Output voltage cannot be set. (Type I
model only)
When the output voltage cannot be set with the master unit or a
few voltages are output at 0 V setting, adjust the variable resis
-
tor for calibration in the following procedure. See page 67, Test
equipment required for calibrationfor the test equipment
required and environment. See Fig. 6-3 for the connection of
the equipment.
・Do not set the output current greater than or equal
to 105 % of the rated current for this adju stment. If
you do, the power supply may malfunction.
■ Adjustment procedure
1. Set the output current to 0 A.
When operating by the front panel (local control), turn the
CURRENT knob counterclockwise all the way. When using ana-
log remote control, set the control signal to 0 V or 0 Ω.
2. Turn on the OUTPUT switch.
CAUTION
