Kikusui PMC 18-5A - Page 82

82 PMC-A
Type II
PMC
18-5A
PMC
35-3A
PMC
70-1A
PMC
110-
0.6A
PMC
160-
0.4A
PMC
250-
0.25A
PMC
350-
0.2A
PMC
500-
0.1A
Protection function
Overvoltage protection
(OVP)
Reset by turning off the POWER switch
ALM LED (red) lights when tripped
Preset range: Approx. 5 % to 105 % of the rated output voltage
Overheat protection
(OHP)
Reset by turning off the POWER switch
ALM LED (red) lights when tripped
OUTPUT turns off when the temperature reaches approx.
110
°C at the built-in heat sink.
Temperature fuse Built into the wire-wound section of the 130 °C power trans-
former
Input
fuse
For 100 V
system
4 A (S.B) [99-02-0155]
For 200 V
system
2 A (S.B) [99-02-0153]
Remote monitoring function
Monitor signal output *9
V MON (voltage)
at rated volt-
age output
10.0 V ± 0.5 V
at 0 V output
0.0 V ± 0.5 V
Monitor signal output *9
I MON (current)
at rated volt-
age output
10.0 V ± 0.5 V
at 0 V output
0.0 V ± 0.5 V
Status signal output *9 , *10
OUTON STATUS Turns on when the OUTPUT is on.
CV STATUS On during CV operation
CC STATUS On during CC operation
ALM STATUS Turns on when the OVP, OHP is activated.
PWRON STATUS Turns on when the POWER is on.
Remote sensing function
Remote sensing Compensate
up to 0.6 V for
a single line.
Not Available
