84 PMC-A
*1 At 100VAC rated load.
*2 A value calculated from the number of windings of the variable resistor. In the ac-
tual case, take 3 times to 5 times this value as a guide line.
*3 With respect to ± 10 % of the line voltage.
*4 With respect to 0 % to 100 % of the output current.
*5 The time it takes for the output voltage to recover within 0.05 % + 10 mV of the
rating when the output current fluctuates in the 10 % to 100 % range.
*6 At a measurement frequencyt bandwidth of 5 Hz to 1 MHz.
*7 The time it takes for the output voltage to rise from 10 % to 90 % of the rating
when the output is turned on.
*8 The time it takes for the output voltage to fall from 90 % to 10 % of the rating when
the output is turned off.
*9 J2 connector on the rear panel.
*10 Photocoupler open collector output. Maximum voltage 30 V, maximum current
(sink) approx. 5 mA. Insulated from the output and control circuits. Status signals
are not mutually insulated.
*11 See the rating of the fuse in the specification of “Protection function”.
Type II
PMC
18-5A
PMC
35-3A
PMC
70-1A
PMC
110-
0.6A
PMC
160-
0.4A
PMC
250-
0.25A
PMC
350-
0.2A
PMC
500-
0.1A
General
Isolation voltage
± 250 V ± 500 V
Weight
Approx. 6.0 kg
(13.23 Ib)
Approx. 5.5 kg
(12.13 Ib)
Approx
5.0 kg
(11.02
Ib)
Dimensions See Fig. 7-2
Accessories
Operation manual 1 pc.
Power cord 1 pc.
Analog remote
control contact
20 pcs.
Analog remote
control plug
1 pc. (attached to the J2 connector on the rear panel)
Lock lever 1 pc. (attached to the analog remote control plug)
Fuse *11 1 pc.
