KINETEC CEM™ 10/22 EN
USING THE HAND CONTROL
7. Session Time
This function allows you to see how long the unit has been operating since it was last reset.
Beginning
Keys to
press
Display Remarks
To stop the unit
FLEX/EXT
50 STOP 15 100
Check whether the hand
control is in the position
or
Press simultaneously on the 2 keys
TOTAL TIME 0125H
RESET: low.limit
The display shows how long
the unit has been operating
since it was last reset.
To reset the counter, press the key
TOTAL TIME 125H
Reset to zero
This message disappears after a
few seconds; the counter is now
reset.
Or
After 5 seconds the time is no
longer displayed, but it remains in
the memory.
FLEX/EXT
50 STOP 15 100
8. Quick Start
Set up the patient and proceed as below:
Beginning
Keys to
press
Display Remarks
Switch the unit ON
KINETEC
ELBOW MODULE
Movement Verif.
Please Wait
Movement Verif.
Motor: M1 M2
ELBOW MODULE
0 STOP 80 135
The last movement used is displayed
To start the session with the parameters
from the previous session.
ELBOW MODULE
0 RUN 10 135
The angle display changes with the current
movement.
Note: the values in the display column are given as an example. In actual use, they will come from stored
programs or previous sessions.
9. Possible values for each parameter
Possible values Default setting
• Treatment mode Normal
• Shoulder positioning 60° to 90° -
• Extension limit -10 to 130° -10°
• Flexion limit -5° to 135° 135°
• Speed
1 to 5 (from 50° to 145° per minute)
2
• Force
1 to 6
6
• Extension pause 0 to 900 seconds (15 minutes) 0
• Flexion pause 0 to 900 seconds (15 minutes) 0
• Timer No timer (00H00) to 24H00 0
