KINETEC CEM™ 16/22 EN
USING THE HAND CONTROL
15. To define the patient tolerance • At the start of a session
This function, MODULATION Mode, allows the maximum limits that a patient can tolerate to be defined and recorded at the
beginning of a session.
Set up the patient and proceed as below:
Beginning
Keys to
press
Display Remarks
Switch the unit ON
ELBOW MODULE
20 STOP 25 90
If Warm Up mode is selected, switch OFF
this mode by pressing the "Warm Up" key.
To select
MODULATION Mode
MODUL. : use + or -
20 STOP 25 90
The display indicates the keys used to run
the machine. This message is displayed 3
seconds.
To select the pain level
(+ key for flexion, - key for extension)
OR
continuously press
MODUL. : use + or -
20 MANUAL 37 90
The unit begins to move as selected.
The settings are controlled by you.
To set the pain level when reached, press
OR
MODUL. : use + or -
37 MANUAL 37 102
The new limit of the movement is recorded.
To start the session with the new movement limits
ELBOW MODULE
37 RUN 37 90
The angle display changes with the current
movement.
Note: when the movement's max. limit (-10° or 135°) is reached, the max. angle is automatically recorded and the function is exited.
16. To define the patient tolerance • During the session
This function, BYPASS Mode, allows the maximum limits that a patient can tolerate to be defined and recorded, which
allows you to work on increasing amplitude.
IMPORTANT: Can be used only when the machine is running.
Beginning
Keys to
press
Display Remarks
The unit is running
ELBOW MODULE
37 RUN 37 90
Check that the hand control is not locked
(See page 9).
To select
BYPASS Mode
BYPASS: use + or -
37 RUN 37 90
The display indicates the keys used to run
the machine. This message is displayed 3
seconds.
To select the NEW pain level
OR
continuously press
BYPASS: use + or -
-5 BYPASS -5 90
The unit begins to move as selected.
The settings are controlled by you.
To set the new pain level when reached, press
OR
BYPASS: use + or -
-5 BYPASS 10 70
The new limit of the movement is recorded.
Continue the session with the new movement limits
ELBOW MODULE
-5 RUN 57 70
The angle display changes with the current
movement.
Note: This function is only available during the warm-up cycles in Warm Up mode.
When the movement's max. limit (-10° or 135°) is reached, the max. angle is automatically recorded and the function is
exited.
17. Session Time
This function shows the running time (in minutes) of the session (motor functioning).
• It is directly accessible by the key , the display shows TIME 02h25
This counter is reset each time the unit is switched ON.
